ZK-120 Diamond wires sharpening machine
Diamond wires sharpening machine is a new processing equipment for whole wires sharpening.
ZK-120 Diamond wires sharpening machine
Diamond wires sharpening machine is a new processing equipment for whole wires sharpening.
Item NO.:
ZK-120Product Origin:
ChinaShipping Port:
XiamenDESCRIPTION:
Diamond wires sharpening machine is a new processing equipment for whole wires sharpening. Servo motor drives the grinding wheel, variable frequency drives the whole wires, combine with PLC sharpening parameters, to achieve automatic sharpening. This machine enables auto tool-setting and grinding, helps to improve production efficiency, achieves perfect sharpening. Meanwhile, this could avoid processing defects such as ellipse, conicity etc. Wires from 14m to 110m with beads’ diameter from Φ6.0 to Φ13.0mm are workable, while 110m above could be customized, high efficiency enables 100m wires sharpened in 20 min. Closed processing environment with dust absorption system ensures clean working condition.
FEATURES:
Dual grinding wheel, dual frequency conversion,dual operation panel.
Automatic grinding device with servo motor and variable frequency driving.
Wire rotation speed controlled via frequency converter.
Personalized mirco-computer interface and digitized display.
Procetion device and dust absorption system.
FUNCTIONS AND TECHNICAL PARAMETERS:
Power Voltage: AC Three-Phase 380v, 50hz (other voltages and frequencies are upon demand)
Wire Outer Diameter: 6-13cm
Wire Length: 14m-120m
Spindle Motor Power: 7.5kw
Main Grinding Wheel Motor Power: 3kw
Vice Grinding Wheel Motor Power: 3kw
Main Swing Motor Power: 0.75kw
Vice Swing Motor Power: 0.75kw
Main Servo Motor Power: 0.75kw
Vice Servo Motor Power: 0.75kw
Overall Dimension(mm): 6000*1900*2400
Net Weight: 4000kg
Grinding Result:
